All-in-one Lotus LED 2 Inch Round Recessed LED 15 Watt High Output Designer Series - 3000 Kelvin - 24 Degree Beam Spread - Chrome Reflector - Trim Copper

2 Inch Round Recessed LED 15W

High Output Designer Series with Interchangeable Reflectors & Trims

• 1,000 lm Output - Designer Series High Performance Fixture
• CRI 90+ for True Color Rendering
• 4 3/8 Inch Thick - Install Where Ceiling Space Is Limited
• Type IC Rated - No Housing Required
• Interchangeable Reflectors and Trims
• Fast and Easy To Install - Save On Labor
• Driver Inside Connection Box - No Junction Box Needed
• 120V Triac Dimmable Driver Included

CONSTRUCTION:
Round 2 Inch fixture with integral Driver in Connection Box.
One driver for every fixture required.

MOUNTING:
Cut hole in ceiling and snap fixture in opening with attached spring clips.
Ceiling Clearance Required: 4 1/2 Inch

• Default Driver Input Voltage: 120V AC 50/60 Hz (Dimmable - TRIAC Dimmers 10%-100%)
• Energy Used: 15W
• Halogen equivalent: 100W
• Beam Angle: 38°(stock) or 24°(custom)
• Light colour: Soft White 3000K
• Light output: 1000 lm
• Ambient Operating Temperature: -4°F (-20°C) to +104°F (+40°C)
• Approved Locations: Insulated Ceilings & Damp Locations
• Rated: cETLus, Energy Star, T24

DIMENSIONS:

• ID 1 7/8 Inch, OD 3 1/8 Inch;Thickness of Trim 1/8 Inch
• Thickness of Reflectors 1 Inch
• Cut out: 2 3/4 Inch
• Junction Box Dimensions (with driver inside): 3 3/4” x 2 1/4” x 1 1/2”

Suitable for Insulated Ceiling & Damp Locations.
